Liquid-filled Sanitary Pressure Gauge 150mm Tri-clamp - YNBF150ZT

Liquid-filled Sanitary Pressure Gauge 150mm Tri-clamp – YNBF150ZT

$0.00

Liquid-filled Sanitary Pressure Gauge 150mm Tri-clamp – YNBF150ZT

Model: YNBF150ZT

Stainless Steel Pressure Gauges / All Models

Request a QuoteEmail Sales

Specifications

Dial Size150mm
Case Material304 Stainless Steel
Wetted Parts316L Stainless Steel
MovementBrass (filled)
WindowSafety Glass
ConnectionTri-clamp (2″ or 2.5″)
Pressure Range-0.1 to 40 MPa
Fill FluidGlycerin (food grade)
Accuracy±1.6% F.S. (Grade A)
Temperature Range-20°C to +65°C
IP RatingIP67

Key Features

  • Large 150mm dial for maximum readability
  • Glycerin filling for vibration damping
  • 3-A Sanitary Standard compliant
  • 316L stainless steel wetted parts
  • Polished surface finish (Ra ≤ 0.8μm)
  • IP67 protection rating

Applications

Large process tanks and vesselsBrewery fermentation tanksDairy processingPharmaceutical reactorsIndustrial food processing
