Pressure Transmitter – SZ-2088

A compact industrial pressure transmitter in a 304 stainless steel housing. It converts the pressure sensed by the piezoresistive element into a standard 4-20 mA or voltage signal for indicating instruments, recorders, regulators and PLC inputs.

Key Specifications

• Measurement range: -0.1 to 60 MPa – custom ranges made to order
• Accuracy: ±0.5% F.S.
• Output: 4-20 mA, 0-5 V, 0-10 V
• Power supply: 24 V DC
• Allowed overload: 1.5 × full scale
• Wetted material: 304 stainless steel
• Process connection: M20×1.5, G1/2, PT1/4

Key Features

• 304 stainless steel wetted parts
• Standard 4-20 mA / 0-5 V / 0-10 V output
• 1.5x full-scale overload allowance
• Three thread standards stocked

Applications

• Oil, gas and petrochemical
• Hydraulic and pneumatic systems
• Water treatment and distribution
• General industrial automation
