Stainless Steel Pressure Gauge 100mm – YNBF100

Model: YNBF100

Stainless Steel Pressure Gauges / All Models

Request a QuoteEmail SalesWhatsApp Us

Specifications

Dial Size100mm
Case Material304 Stainless Steel
Wetted Parts304 Stainless Steel
MovementBrass
WindowSafety Glass or Polycarbonate
Connection1/4″ or 1/2″ PT, NPT, or G
Pressure Range-0.1 to 100 MPa
Accuracy±1.6% F.S. (Grade A)
Temperature Range-40°C to +70°C
IP RatingIP65

Key Features

  • All-stainless steel construction
  • Safety glass window (polycarbonate option)
  • Large 100mm dial for easy reading
  • Multiple connection sizes and types
  • Liquid-filled version available (YNBFL100)
  • IP65 protection rating

Pressure Ranges

CodeRange (MPa)Range (bar)
V010~0.06 MPa0~0.6 bar
V020~0.1 MPa0~1 bar
V030~0.16 MPa0~1.6 bar
V040~0.25 MPa0~2.5 bar
V050~0.4 MPa0~4 bar
V060~0.6 MPa0~6 bar
V070~1 MPa0~10 bar
V080~1.6 MPa0~16 bar
V090~2.5 MPa0~25 bar
V100~4 MPa0~40 bar
V110~6 MPa0~60 bar
V120~10 MPa0~100 bar
V130~16 MPa0~160 bar
V140~25 MPa0~250 bar
V150~40 MPa0~400 bar
V160~60 MPa0~600 bar

Dimensions

Diameter100mm
Panel Cutout102mm
Connection Size1/4″ or 1/2″ PT/NPT/G
Connection LocationLower mount (LM) or Center back (CB)

Applications

Industrial process controlHydraulic systemsCompressors and pumpsChemical processingPower generationMining and minerals
