Stainless Steel Pressure Gauge 100mm - YNBF100T

Stainless Steel Pressure Gauge 100mm – YNBF100T

$0.00

Stainless Steel Pressure Gauge 100mm – YNBF100T

Model: YNBF100T

Stainless Steel Pressure Gauges / All Models

Request a QuoteEmail Sales

Specifications

Dial Size100mm
Case Material304 Stainless Steel
Wetted Parts316L Stainless Steel
MovementBrass
WindowSafety Glass
ConnectionTri-clamp (standard sizes: 1.5″, 2″)
Pressure Range-0.1 to 40 MPa
Accuracy±1.6% F.S. (Grade A)
Temperature Range-40°C to +70°C
IP RatingIP65

Key Features

  • 3-A Sanitary Standard compliant design
  • 316L stainless steel wetted parts
  • Polished surface finish (Ra ≤ 0.8μm)
  • Tri-clamp connection for easy installation and cleaning
  • CIP (Clean-In-Place) and SIP (Sterilize-In-Place) compatible
  • Safety glass window

Dimensions

Diameter100mm
Total Height~85mm (without clamp)
Tri-clamp Size1.5″ or 2″
Diaphragm Diameter32mm (1.5″) / 40mm (2″)

Applications

Dairy and milk processingBrewery and beverage productionPharmaceutical manufacturingBiotechnologyCosmetics productionFood processing lines
