YN40BF - Stainless Steel Pressure Gauge 40mm

YN40BF – Stainless Steel Pressure Gauge 40mm

$0.00

YN40BF – Stainless Steel Pressure Gauge 40mm

Model: YNBF40

Stainless Steel Pressure Gauges / All Models

[← Back to Product List](https://upscalegauge.com/category/stainless-steel-pressure-gauges/)

Request a QuoteEmail Sales

Specifications

Dial Size40mm
Case Material304 Stainless Steel
Wetted Parts304 Stainless Steel
MovementBrass
WindowSafety Glass
Connection1/4″ PT or NPT
Pressure Range-0.1 to 40 MPa
Accuracy±1.6% F.S. (Grade A)
Temperature Range-40°C to +70°C
IP RatingIP65
M01-0.1~0.06
M02-0.1~0.15
M03-0.1~0.3
M04-0.1~0.5
M05-0.1~0.9
M06-0.1~1.5
M07-0.1~3.0
M08-0.1~5.0
M09-0.1~10
M10-0.1~15
M11-0.1~20
M12-0.1~25
M13-0.1~30
M14-0.1~40
Diameter40mm
Panel Cutout42mm
Connection Size1/4″ PT/NPT
Connection LocationLower mount (LM)
SKU: YNBF40 Category:
