Intelligent Digital Display Pressure Controller (Dual Relays) – YK-902-1

An intelligent digital pressure controller with dual relay outputs. The display reads in MPa, kg/cm2 and psi, and the relay outputs switch upper and lower limits directly at the set point.

Key Specifications

• Mounting: Radial (bottom connection)
• Measurement Range: 0 to 60 MPa – custom ranges made to order
• Accuracy Class: 1.0
• Power Supply: DC 12 V / DC 24 V / AC 220 V / AC 380 V
• Switch Output: Dual relays (common / lower limit / upper limit)
• Installation Thread: M20x1.5, M14x1.5, G1/2, G1/4, PT1/4

Key Features

• Local digital reading with dual relay outputs
• MPa / kg/cm2 / psi unit switching
• Five thread standards stocked
• Custom ranges made to order

Applications

• Pump and compressor control
• Hydraulic equipment
• Water supply and booster systems
• Automation machinery
