Sanitary Digital Pressure Gauge 60mm Clamp – YS60-MC

A battery-powered digital pressure gauge on a tri-clamp sanitary fitting. Runs on three AAA cells, so it goes anywhere on a food, beverage or pharmaceutical line without a cable run.

Key Specifications

• Dial Size: 60mm
• Accuracy Class: 0.4
• Pressure Range: 0 to 1.6 MPa (nameplate) – custom ranges made to order
• Process Connection: Tri-clamp 50.5
• Power Supply: Three AAA batteries

Key Features

• Battery powered — no cable run needed
• Tri-clamp sanitary fitting
• 0.4 class digital reading
• Compact 60mm head

Applications

• Food and beverage processing
• Dairy and brewing
• Pharmaceutical and biotech
• Portable spot checks
