Axial Threaded Diaphragm Pressure Gauge 60mm – YTP60ZML

An axial 60mm diaphragm-sealed pressure gauge for corrosive, viscous or crystallizing media. The 316L diaphragm isolates the movement from the process, and the threaded connection suits compact pipeline installations.

Key Specifications

• Dial Size: 60mm
• Mounting: Axial (bottom connection)
• Measurement Range: 0.1 to 2.5 MPa, vacuum / negative pressure – custom ranges made to order
• Accuracy Class: 2.5
• Diaphragm Material: 316L stainless steel, PTFE lining optional
• Case Material: Stainless steel
• Process Connection: M14x1.5, G1/4, M20x1.5, G1/2
• Filling: Glycerin

Key Features

• 316L diaphragm isolates the movement from the process
• PTFE lining optional for aggressive media
• Custom ranges made to order
• Stainless steel case

Applications

• Chemical and petrochemical
• Oil and gas processing
• Water treatment and distribution
• Pump and compressor systems
